Product Description

Second generation inverted image intensifier

This series of image intensifiers use electrostatic focusing electronie optical system, magnification of 1 or greater than 1, small size, lightweight,distortion correction. Use S-25 photocathode, microchannel plate, P20 or P39 sereen.

Features:

Integrated power supply

External gain control function

Automatic Brightness Control (ABC)

High intensity light source (BSP) protection

It can be used in the complex environment of high temperature, 1ow temperature,vibration and impact

Wire/contact input interface

Anti-corona discharge glass can be added

Application:

pilot

The commander mirror

Night vision system for fire control

Long range sight

Astronomical observations

Weak light study



Per formance parameters:







model

1XZ20/30W-3

1XZ25/25W-2

Effective working
diameter





Input the mm

20

25

Output the mm

30

25

Window material





The input

Optical fiber panel

Optical fiber panel

The output

Optical fiber panel

Optical fiber panel

Photocathode type

S25

S25

Screen type

P20

P39

Photocathode
sensitivity





2856 k mu A/lm

300

300

800nm mA/W

25

25

850nm mA/W

20

20

The resolution of
the





The center of the
lp/mm

46

36

The edge of the
lp/mm

40

32

Gain
CD/mundefined/lx

8000

16000

Equivalent
background
illumination ulx

0.2

0.2

Signal-to-noise
ratio(108 mu Ix)

3.2

3.2

magnification

1.5

1

Input current mA

3
0

32

Input voltageV

2.7

2.7

mum mass g

350

360

ermal dimension

Φ62x80

Φ63x76



Specifications︰Second generation inverted image intensifier
Advantages︰This series of image intensifiers use electrostatic focusing electronie optical system, magnification of 1 or greater than 1, small size, lightweight,distortion correction.
