Model No.︰YJRQ-325
Brand Name︰OUTLOOK
Country of Origin︰China
Minimum Order︰1 pc
Share on:

 Total 76 Related Items
Prev1415161718Next

Product Description

The YJRQ-325 multifunctional thermal imaging uses vanadium oxide uncooled focal plane detector and real-time digital image processing circuit. Can work continuously day and night. At the same time, it has the ability to penetrate fog, smoke and dust particles, and can synchronously complete search, reconnaissance and aiming shooting actions. It is the ideal assistant for anti-terrorism, law enforcement, anti-smuggling and anti-drug.

Features:
*Advanced FPGA image processing technology

*384X288/640X480 (optional) High resolution
*50/60Hz real-time imaging, fast movement without drag
*Unique digital enhancement algorithm to find targets in harsh environments
*Professional telephoto germanium lens, 2x, 3x, 4x digital zoom
*White heat/black heat/red heat/brown/iron red/rainbow variety of colors available
*Full metal housing, 6000 coke high impact design
*Very low power consumption, 1 battery can work continuously for 8 hours
*Easy to use buttons and numeric menus
*Level 10 sharpness enhancement, level 8 intelligent noise reduction
*100 level brightness control, 100 level contrast control
*Manual and fully automatic image enhancement modes
*The system has high reliability, strong anti-fall and anti-seismic ability
*Strict and reliable waterproof performance, suitable for all-weather indoor and outdoor use



Model number

YJRQ325

Detector resolution

384*288,  17um

Sensitivity

40mk f/1 300K

Spectral range

8~14μm

Lens focal length

25F# 1.0

Field Angle

10.7°x 8°

Discovery distance

1500m

Focusing distance

10m- Infinity

Video output

RS170 CCIR/ PAL composite video

Reveal

2.5LCD /960x240 pixels

Image polarity

White heat, black heat, brown, red heat, iron red, rainbow

Image sharpness

0-9

Battery

3.7V rechargeable lithium battery

Operating temperature

4H

Storage temperature

-20~+50

Storage temperature

-30~+60

Product size (L x W x H)

110mm (L)x Φ75 mm x80mm

Electrical interface

Aviation plug EGG-9

Housing material

Aero-aluminium alloy

Weight

644g

Specifications︰YJRQ-325
Advantages︰*Advanced FPGA image processing technology
*384X288/640X480 (optional) High resolution
*50/60Hz real-time imaging, fast movement without drag
*Unique digital enhancement algorithm to find targets in harsh environments
*Professional telephoto germanium lens, 2x, 3x, 4x digital zoom
*White heat/black heat/red heat/brown/iron red/rainbow variety of colors available
*Full metal housing, 6000 coke high impact design
*Very low power consumption, 1 battery can work continuously for 8 hours
*Easy to use buttons and numeric menus
*Level 10 sharpness enhancement, level 8 intelligent noise reduction
*100 level brightness control, 100 level contrast control
*Manual and fully automatic image enhancement modes
*The system has high reliability, strong anti-fall and anti-seismic ability
*Strict and reliable waterproof performance, suitable for all-weather indoor and outdoor use

Min Order︰1
